DP-E6B LITE-PUTER
Controller / Interface
DP-E6B replaces the DP-6 with more features. It controls 256 channels, stores 100 scenes. It has the timer functions for automatically executive scenes according to the schedule that has been set.
Specifications:
-
256 channel output, standard DMX
-
RS-485 interface: connect with CP-2B/ CP-3B
-
Connecting with several CP-2B/ CP-3B, can be set up to 8 sections and can be used in the room with partitions
-
4 sets of 9-pin D-type connector for CP-2B/ CP-3B
-
Up to 10 sets of CP-3B control panel can work together, or independent
-
100 memory scenes and per scene can control 256 channels
-
AC input: 90 - 240VAC switching power supply
-
DC output: 12VDC 1A (for CP-2B/ CP-3B use)
-
Automatic protection system for output short, recovery automatically after short
-
LCD display for year, month, week, day, hour, minute, second
-
Reset switch: to re-start the system
-
Timer function: 1440 points can be set by minute
-
Fader function: Each scene can be set fader time 0.1 sec. 90 min
-
Function of detecting solar light
-
Baud rate: 250k bits / sec
-
Transmission distance up to 1km
-
AC Power input AC100-240V
-
DMX signal input RS-485 or DMX512/ 1990
-
DMX signal output DMX512/ 1990
-
DMX signal connector XLR 5pin
-
Rack size 19", 2U rack mountable
-
Size: 4"x19"x4"
-
Weight 2.8 kgs/6.2 lbs
SALE: $879.99
FREE S&H in continental US (e-mail for international / offshore USA rates)
