PRESONUS STUDIOLIVE 32R AVB 32 Channel CAT5e/6 Rackmount Digital Mixer/StageBox Snake

 STUDIOLIVE 32R  PRESONUS

 32 Channel Rackmount Digital Mixer/Stage Box

The PreSonus StudioLive 32R is a 34-input, 32-channel Series III stage box and rack mixer. It serves as either a simple stage box or a combination stage box and monitor mixer. Since Series III rack mixers and consoles can network using AVB, you can connect your StudioLive 32R to a Series III front-of-house console with one lightweight CAT5e or CAT6 Ethernet cable, eliminating the need for a heavy, expensive copper snake—and the signal degradation that goes with long analog cable runs. You can even remote control the StudioLive 32R’s preamps and phantom power from your networked Series III console. In stage box + monitor mixer mode, the StudioLive 32R not only serves as an excellent networked stage box, it is a full blown monitor mixer with far more processing and mixing power than any mixer in its class—all packed into just two rackspaces (2U). The StudioLive 32R features studio-quality converters with 115 dB dynamic range and 48 kHz operation with 24-bit resolution. With scenes and presets you can create, save, and edit up to 100 scenes. It also has an onboard stereo SD recorder.


Features:

• 34 total inputs (32 mic/line channel inputs + 2 RCA inputs)

• 16 - 1/4" TRS FlexMix outputs

• Ethernet control network port

• Onboard stereo SD recorder

• 40x40 USB recording interface

Specifications:


Power / Environmental

• Connector: IEC

• Input-Voltage Range: 90 to 230 VAC (±10%)

• Power Requirements (continuous): 85W

• Recommended Ambient Operating Temperature: 0° to 40° Celsius / 32° to 104° Fahrenheit

System Requirements

Mac:

• Mac® OS X 10.8.5 64-bit or later

• Intel® Core™ 2 Duo processor (Intel Core i3 or faster recommended)

• 4 GB RAM (8 GB or more recommended)

Windows:

• Windows® 7 x64/x86 SP1 + platform update, Windows 8.1 x64/x86, Windows 10 x64/x86

• Intel Core 2 Duo (Intel Core i3 or faster recommended)

• 4 GB RAM (8 GB or more recommended)

Mac and Windows Systems:

• USB 2.0 port

• Internet connection

• Internal or external 7200 RPM storage drive highly recommended

• 34 GB hard disk space

• Monitor with 1366x768 resolution

iOS:

• iOS 9.3 or later

• iPad Pro, iPad Air 2, iPad Air, iPad mini 4, iPad mini with Retina display, iPad (4th generation), iPad mini, iPad (3rd generation), iPad 2?

• Android (QMix-UC)

• Android™ 5.0 (Lollipop) or later

• Android smartphone (QMix-UC)

• Android tablet (8-inch) with 1024x768 resolution (UC Surface)

Physical

• Dimensions: 3.5" x 19" x 12"

• Weight: 11.2 lbs

SALE: $2299.99

FREES&H in continental US (e-mail for international / offshore USA rates)
