WARM AUDIO EQP-WA Professional Rackmount Classic Style Tube Equalizer Processor

 EQP-WA  WARM AUDIO

 Classic Tube Equalizer Processor

In the EQP-WA, Warm Audio has, in essence, re-created one of the most renowned tube Equalizers in studio history—the "Pultec EQP-1A." The goal was to bring to market an affordable equalizer of this magnitude for the first time, with no compromise in the quality and design parameters that make this type of equalizer so desirable. Not only does its look and feel match the classic Pultec, but its sonic quality has also been carefully considered and reproduced with the implementation of top-end components like CineMag USA transformers and premium-quality tubes. This fully-discrete Tube EQ can pull out euphoric sonics from any track and bring a luster and brilliance to mixes that’s extremely difficult to achieve inside-the-box.

Features:

• Tube Equalizer based on the classic “Pultec” EQP-1A

• CineMag USA input and output transformers

• Premium high voltage 12AX7 and 12AU7 tubes

• CineMag USA inductor EQ section

• Bypassable EQ section - although signal still passes through tubes and transformers for warming effect

• No insertion loss - loss restored by tube amplifier

• XLR and TRS transformer balanced inputs

• XLR and TRS transformer balanced outputs

• Boost and Cut controls can be used simultaneously for phase effect

• (5) added frequency points for greater flexibility

• Switchable 115/230 Volt IEC power inlet

Specifications:

• Frequency Response: 20 Hz - 50 kHz, +/- 1 dB

• Self Noise: < -75 dB

• Input Impedance: 600 Ω

• Output Impedance: Capable of driving a 600 Ω load

• Power: Selectable 115 V 60 Hz/230 V 50 Hz via standard grounded 3 conductor IEC cable

• Fuse Compliment: 1 amp, 250-volt

• Input: Transformer balanced, pin 2/tip=positive, pin 3/ring=negative, pin 1/sleeve=ground

• Output: Transformer balanced, pin 2/tip=positive; pin 3/ring=negative, pin 1/sleeve=ground

• Low frequency boost: 20, 30, 60, 100, 200, 400, 800 Hz - 12 db

• Low frequency cut: 20, 30, 60, 100, 200, 400, 800 Hz - 18 db

• High frequency boost: 3, 4, 5, 8, 10, 12, 16 kHz - 18 db

• High frequency cut: 3, 4, 5, 10, 20 kHz - 14 db

• Dimensions: 19" x 3.5" x 6" - 2U rack-mountable

SALE: $799.99

FREE S&H in continental US (e-mail for international /offshore USA rates)
