ALLEN & HEATH DX012 12 XLR Output Analog / AES Portable DX Expander

 DX012  ALLEN & HEATH

 12 XLR Output Analog / AES Portable DX Expander

If you need to get more out of your system, just look to the Allen & Heath DX012. It's designed to provide remote output expansion for their SQ and dLive models. It's ideal for feeding IEM systems as well as amplifier racks, offering both analog and AES digital output options in a compact 1U package.

Each unit provides 12 XLR outputs which can be configured in several ways

• 12 analog line outputs

• 8 analog line outputs + 4 stereo AES outputs

• 4 analog line outputs + 8 stereo AES outputs

• This useful input/output (I/O) device is connectable through a single Cat5e cable to the dLive Surface, dLive MixRack and SQ mixer, or upstream DX expander via a secure EtherCon port.

• A second locking EtherCon port is also included for redundant connection to other compatible hardware, or for daisy-chaining to a downstream DX expander for additional remote I/O.

Features:

• Compatible with SQ and dLive systems

• Rack-mounted (1U) or shelf/floor operation

• Plug and Play: no IP addressing required

• Compatible with CAT5e (or higher) cables of up to 100m

• Locking EtherCon ports

12 XLR Outputs

• 1-4 Analog Line Out

• 5-8 Analog Line out or AES Digital out (switchable)

• 9-12 Analog Line out or AES Digital out (switchable)

AES outputs globally switchable between

• 44.1 kHz

• 48 kHz

• 88.2 kHz

• 96 kHz

• Cascade mode allows daisy-chaining of 2 DX16/DX12 Expanders for additional I/O

• Redundant DX connection to compatible hardware

Multiple DX012 can be added to a system

• Up to 16 DX012 units can be added to a SQ system

• Up to 46 DX012 units can be added to a dLive S Class system

• Up to 22 DX012 units can be added to a dLive C Class system
