AMERICAN DJ WMX1 MKII Wolfmix Stand Alone Lighting Controller

 WMX1 MKII   AMERICAN DJ

 Wolfmix Stand Alone Lighting Controller

The ADJ Lighting WMX1 MKII, powered by Wolfmix, is a standalone lighting control system designed with the performer in mind. Featuring a 4.3” color touchscreen display and 37 backlit silicone buttons, it allows intuitive hands-on control of a DMX lighting setup. It features a toolbox of FX modules and eight independent fixture groups which allow for the simple creation of high-impact light shows on the fly without a computer. Ideal for mobile entertainers as well as bars, clubs, and entertainment venues, this compact but powerful controller puts creative lighting control at any user’s fingertips.

Setup

• Standalone (no computer needed)

• Compatible with any DMX device

• Standard unit comes with 1 DMX universe but up to 3 additional universes are available

• as add-ons, which are sold via the WTOOLS app.

• Up to 680 fixtures & beams

• Up to 50 fixture types

• Up to 5000 fixture features (color/gobo etc...)

• 8 fixture groups

• 6 projects

• 15000+ available fixtures (3500+ on the controller)

• DMX address, fixture order & group setup

• Use as a DMX splitter with DMX universe mapping

Palettes & FX

• Color FX module with 8 effect types & 16 definable colors

• Move FX module with 8 effect types

• Beam FX module with 8 effect types

• 6 Flash buttons for controlling Special FX, Strobe, Blinder, Speed,

Blackout & Smoke

• Static color palette with 10 user definable colors per group & gradient control

• Static position palette with 5 user definable positions per group with fade & fanning

• Gobo palette with 5 user definable gobos per group

• 20 namable live edit buttons with flash triggering mode and ‘Park’ function

• 100 namable presets for storing snapshots with hold and fade timings

• Preset playback cue list- all presets or per page of 20 presets

Control & Sync

• Group and master dimming with encoder acceleration

• Group FLASH, FULL and Blackout

• 16-bit Pan/Tilt control

• Multi-beam LED bar control

• FX music pulse sync from Microphone or Line-In

• FX BPM sync with Ableton Link, OS2L or BPM TAP

• Effect Speed, Phase, Order, Size, Fade, Fan & Flick

• Live control of move FX registration point

• Global FX speed and freeze control

• Map DMX IN with group dimmer and patch to output channels*

• WLINK - sync with another Wolfmix controller

Built-in tools

• Fixture Builder

• Fixture calibration tool, to limit the area of moving fixtures

• X-Y touch-controlled positioning grid

• RGBW touch controlled color picker

• 8-step real time sequencer for creating beam and move FX

• Live view of DMX levels with default value override and DMX channel tester

• Beam Editor to override Min and Max values used in generated FX

Other neat features

• Calibrate and RGB, White, Amber, UV mixing with automatic fixed color wheel translation

• Automatic matching of similar gobos across different fixture types

• Timed release of flash and preset buttons

• Fixture FLIP function, for reversing beam order

• Fixture SPLIT function, for splitting up multi-FX bars

• Lock full controller, or lock editing with a password

• Project & fixture backup with WTOOLS app

• Offline 3D visualization with Easy View & WTOOLS over USB*

• Auto-recovery of active project (no manual saving needed)

• Import different fixture setups into the same project

• Starts in under 2 seconds. Starts sending DMX in under 1 second

• Factory firmware startup recovery mode for times of crisis

• *some features require an add-on purchase available through the WTOOLS app

Display

• 4.3” Color TFT with tinted glass

• Capacitive touch

• Encoders

• Full body alloy

• Incremental push with acceleration

Button pads

• 37 Silicone buttons with matt oil finishing

• LED color backlit

Processing

• 220Mhz CPU with ARM core

• 8MB RAM

• 16MB Flash

Audio

• Omnidirectional electret mic

• 3.5mm Jack Line-In

• Analog adaptive peak detector

DMX

• 2x 3-pin DMX OUT XLR connectors

• 1x 5-pin DMX OUT XLR connector

• 1x 5-pin DMX IN/OUT XLR connector with WLINK

Housing

• ABS Plastic

• Powder-coated steel base plate with 100mm VESA (M4 6mm max)

• Powder-coated steel reinforced back plate

Size & Weight

• 195 x 220 x 62 mm / 7.68 x 8.66 x 2.44 in

• 1070g / 2.36lb

SALE: $699.99

FREE S&H in continental US (e-mail for international / offshore USA rates)
