ENTTEC D-SPLIT 70579 4-Way 5-Pin & 3-Pin DMX Optical Isolator/Splitter Interface

 D-SPLIT 70579  ENTTEC

 4-Way 5-Pin & 3-Pin DMX Optical Isolator/Splitter

The D-SPLIT is a 1 to 4 DMX 512 splitter, allowing you to send your signal in different directions or to increase the number of fixtures that you can send your signal to (DMX signal is limited to running through 32 fixtures).

Features:

• Lightweight and portable

• 1 DMX input: Both [70578] [70579] offer flexibility of 3-Pin and 5-Pin male connector for connection to only 1 DMX input

• 4 DMX outputs (choose between 2 SKU): [70578] Two 5-PIN and two 3-PIN outputs for greater flexibility, [70579] All 5-PIN DMX outputs

• All outputs are optically isolated (protects against up to 1000V of stray voltage).

• DMX512-1990 compatible

• Controls up to 512 channels

• LED indicators show Power and DMX output

• External 12V power supply (included)

• Controls up to 512 channels

• LED indicators when powered

• External power supply (included)

Specifications:

• DMX512 Optical isolator/splitter

• DMX Input Connectors: 1x 5 Pin DMX, 1x 3 Pin DMX (Only one input is allowed. No output/error with 2 input signals simultaneously.)

• DMX Output Connectors: 4x 5 Pin DMX

• Max Output Channels: 1 universe (512ch)

• Supported Protocols: DMX512-1990

• RDM compatibility: No

• Environmental operating temperature: 0°C to 50°C, 32°F to 122°F

• Environmental operating humidity: 5- 95% (non-condensing)

• LED indicators: Power & Data Output

• Insulation Rating: IP20

• Current Draw; 400Ma

• Power Input: 7V-24vDC

• Size: Width 4.6" x Height 3.43" x Depth 2.05"(116 x 87 x 52mm)

• Weight: 0.16 kgs / 0.35 lbs

• Color: Black

• Material: ABS plastic

SALE: $169.99

FREE S&H in continental US (e-mail for international / offshore USA rates)
