ENTTEC DIN ETHERGATE POE 2 Universe eDMX to DMX Converter Interface

 DIN ETHERGATE POE  ENTTEC

 2 Universe eDMX to DMX Converter Interface

ENTTEC’s DIN ETHERGATE is a robust and reliable installation grade DMX node engineered to take any architectural, commercial or entertainment project to the next level.

With 2 universes of bi-directional eDMX -> DMX conversion and ArtRDM support, the DIN ETHERGATE is a flexible, cost effective method to connect physical DMX devices to your network infrastructure.

All configuration is managed through the localhost web interface to simplify commissioning.

The DIN ETHERGATE’s slim, 4 DIN-module electrically insulated housing supports TS35 DIN and surface mounting for fast installation. Pluggable terminal blocks with inbuilt termination line make wiring simple.

Power the DIN ETHERGATE using power over ethernet (PoE) or 7-24v DC input.

Features:

• Two bi-directional DMX/ E1.20 RDM ports with optional termination and RDM support

• Support for Art-Net 4, sACN and ESP

• Supports DMX -> Art-Net Broadcast or Unicast

• HTP/LTP merging support for up to 2 DMX sources

• Configurable DMX output refresh rate

• Surface or TS35 DIN rail mount

• Supports IEEE 802.3af PoE (Power over Ethernet) or DC 7-24v input

• Intuitive device configuration and updates through the inbuilt web interface

• DHCP or static IP Address support

• 10/100 Mbps network speed

• ‘Current DMX Buffer’ allows DMX values to be viewed per port

Specifications:

• Two universe bi-directional eDMX -DMX/RDM gateway in a compact 4-module DIN-rail form factor

• Connectors: 1* LAN port (RJ45) 2* Bi-directional DMX (4 Pin Phoenix) 1* Power Input (2 Pin Phoenix)

• LED Indicators: Forward facing status indicator, Network Link / Activity indicators (RJ45 Port)

• Profile storage on hard drive or import/export to USB key or FTP

• eDMX protocols: Art-Net, Art-RDM, sACN, ESP

• DMX protocols: USITT DMX512-A, ANSI E1.20 RDM

• DMX & RDM timings: Break time 200ms, Mark after Break (MAB)20ms

• Art-Net merging:2 Sources

• Max. channels: 2 universes (1024ch)

• Max. refresh rate: 43FPS

• Network Speed 10/100Base-T

• Power over Ethernet: IEEE 802.3af

• Network configuration: Static (default 192.168.0.10) / DHCP

• Firmware updates Through web interface Inbuilt DMX termination Yes

• Operating Temperature: 0°C to 50°C / 32°F to 122°F

• Operating Humidity: 5- 95% (non-condensing)

• Power Input: 7-24vDC

• ax. current draw 7W

• Rack mountable (19" x 1U)

• Integral cooling fan

• Insulation Rating: IP20

• Dimensions: 3.96" x 2.85" x 1.34" (100.5x72.25x34mm)

• Weight: 0.11 kgs / 0.24 lbs

• Body Material: ABS plastic

• Mounting options: Surface mount, TS35 DIN-Rail mount

SALE: $299.99

FREE S&H in continental US (e-mail for international / offshore USA rates)
