EV EKX-12 Passive Lightweight 12" PA Speaker System

 EKX-12  EV

 Passive 12" PA System

The EKX series is the newest member of the Electro Voice portable loudspeaker family, and combines legendary EV sound quality and reliability with the latest technology — all in a compact package suitable for a wide range of sound reinforcement scenarios, including musicians/DJs and live/club/installed sound applications. The EKX series features eight models (four powered and four passive), including 12" and 15" two-way models and 15" and 18" subwoofers. EKX is positioned above the ZLX and ELX series and below the ETX series.

Features:

• EKX-12: 1400 W (peak), 131 dB peak SPL utilizing high-sensitivity transducers designed and engineered by EV.

• EV-patented Signal Synchronized Transducers™ (SST) waveguide design provides precise and consistent coverage.

• Lightweight, compact 15-mm wood enclosure with internal bracing, and durable EVCoat finish.

• Eight M10 threaded mounting points, aluminum pole mounts, and all-metal handles.

• 90° x 60° pattern for best coverage on mid-size stages. 40° monitor angle with rubber feet.

Specifications:

• Axial Sensitivity (SPL, 1 W @ 1 m): 95 dB

• Connector Type: Dual NL4

• Coverage (Nominal -6 dB): H 90 °

• Crossover Frequency: 1.6 k Hz

• Enclosure Material: 15 mm, plywood with EVCoat

• Frequency Response (-10 dB): 55 Hz - 20 k Hz Full Space Measurement

• Frequency Response (-3 dB): 82 Hz - 18 k Hz Full Space Measurement

• Grill: 18 AWG steel with powder coat

• HF Transducer: DH-1M 1-inch titanium compression driver

• LF Transducer: EVS-12M 300 mm (12 in)

• Maximum SPL: 131 dB

• Minimum Impedance: 7.5 Ohm

• Nominal Impedance: 8 Ohm

• Power Handling (Continuous / Peak): 350 W/1,400 W

• Recommended High-Pass Frequency: 55 Hz

• Shipping Weight: 21.4 kg (47.18 lbs)

• Suspension: (8) M10 threaded mounting points

• Height: 14RU 607 mm (23.9")

• Width: 375 mm (14.76")

• Depth: 356 mm (14.02")

• Weight Net: 17.4 kg (38.36 lbs.)

SALE: $1559.99

FREE S&H in continental US (e-mail for international / offshore USA rates)
