OBSIDIAN NX-TOUCH Portable DMX Control Surface with Electronic Faders

 NX-TOUCH  OBSIDIAN

 Portable DMX Control Surface

The NX Touch is an effective yet simple control surface for the ONYX platform. It is fully compatible with all ONYX consoles and PC software. The NX Touch is a plug-and-play solution with an innovative control surface.

14 touch faders allow control of playbacks and fixture parameters while 20 velocity-controlled pads allow for new types of effects. Additional programming buttons such as Record, Edit, Update, Load and Clear are accessible directly from the NX Touch control panel. NX Touch includes one DMX port for direct control of any compatible DMX device.

Features:

• USB control surface for both smaller applications and professional use

• Combined playback and programming surface with innovative touch fader technology

• Pressure sensitive flash buttons

• 10 Playbacks, 10 multi-purpose function keys, 4 digital encoders

• Portable, rugged and lightweight design

• USB connection for ONYX on PC systems or as expansion wing for all ONYX consoles

• Integrated DMX output, expandable up to 128 Universes

• Plug and Play USB device without external power supply

• Rackmount option

Specifications:

SURFACE

• Bank Navigation Up/Down with numerical display

• Main Go section: Snap, Release, Pause and Go buttons

• Command Buttons: Record, Edit, Update, Load, Clear

• Multifunction Mode Select button

• Fixture Selection buttons: Last, Next, Highlight

• 4 x Parameter Select buttons

• 4 x Parameter Adjust touch faders

• 10 x Function velocity pads

• 10 x Playback touch faders with 3 buttons

• (2 x touch pad, 1 x velocity pad)

CONNECTIONS

• DMX Out: 1 x 5-pin locking XLR

• USB Input: USB B 2.0

REQUIREMENTS

• Windows 10

• Intel Core i3 processor 6th Generation+

• 4 GB RAM

• 2 GB available disk space (SSD recommended)

• Widescreen monitor, minimum 1280 wide, 768 high (capacitive multi-touchscreen recommended)

• USB 2.0 port

• 10/100 Ethernet port for Art-Net DMX output

• 100/1000 Ethernet port for X-Net, Remote operation and sACN

PHYSICAL ELECTRICAL

• Length: 394 mm (15.5 in.) Power source: 5 VDC over USB:

• Width: 218.5 mm (8.6 in.) Maximum current: 500 mA

• Height: 46.5 mm (1.8 in.)

• Weight: 4.6 kg (10.2 lbs.)

• Housing: Aluminum, steel, plastic

• Mounting: VESA 75x75, 100x100

• Security: K-Lock locking slot

• IP Rating: IP20

INCLUDED ITEMS

• Dust Cover

SALE: $749.99

FREE S&H in continental US (e-mail for international / offshore USA rates)
