SENNHEISER EW 100 G4-Ci1 Guitar Wireless Rackmount System with Built-in EQ & Tuner

 EW 100 G4-Ci1  SENNHEISER

 Evolution Series Guitar Wireless System

Fully engineered for professional live applications, the ew 100 G4-Ci1, a part of Sennheiser's evolution wireless G4 series, is a rugged all-in-one wireless system that works great for guitar, bass, and more. Its robust SK 100 G4 bodypack transmitter and Ci1 instrument cable as well as an EM 100 G4 rack-mount receiver (GA 3 rack kit included) all make for a system that delivers for daily use on stage.

G4 100 Series
For those who sing, speak, or play instruments, this series offers versatile wireless systems with up to 42 MHz tuning bandwidth, all in a stable UHF range, and including fast, simultaneous setup of up to 12 linked systems.

Sennheiser ew 100 G4-Ci1 Includes:

• (1) EM 100 G4 true diversity receiver

• (1) SK 100 G4 bodypack transmitter

• (1) Ci 1 instrument cable

• (1) GA 3 rack-mount set

• (1) power supply

• (2) AA batteries

• (2) rod antennas

• (1) RJ 10 cable

• (1) quick guide

• (1) safety guide

• (1) manufacturer declaration sheet

• (1) frequency supplement sheet

Sennheiser evolution wireless G4 100 Series Features:

• "Evolving" with you: Flexibility, Safety, Power.

• Engineered for professional live sound: Rugged all-in-one wireless system for singers and presenters.

• Robust bodypack transmitter and durable Ci 1 instrument cable for daily use on stage

• True diversity half-rack receiver in a full-metal housing with intuitive LCD display for full control

• Easy and flexible wireless synchronization between transmitter and receiver via infrared

• Fast frequency allocation for up to 12 receivers via linking functionality

• Up to 20 compatible channels

• Up to 42 MHz bandwidth with 1680 selectable frequencies, fully tunable in a stable UHF range

• Transmission Range: up to 300ft (100m)

• High RF output power (up to 30 mW) depending on country regulations

Sennheiser ew 100 G4-Ci1 Specifications:

• EM 100 G4 Receiver

• Frequency range:

• A1: 470 - 516 MHz

• A: 516 - 558 MHz

• G: 566 - 608 MHz

• Dimensions: Approx. 190 x 212 x 43mm

• Compander: Sennheiser HDX

• THD, total harmonic distortion: = 0.9 %

• Weight: Approx. 980 g

Audio output

• 6.3 mm jack socket (unbalanced): +12 dBu

• XLR socket (balanced): +18 dBu

• Signal-to-noise ratio: = 110 dBA

• Switching bandwidth: up to 42 MHz

• Peak deviation: ±48 kHz

• Nominal deviation: ±24 kHz

• Operating time: Typically 8 h

• Modulation: Wideband FM

• Power supply: 12 V DC

• Antenna connector: 2 BNC sockets

• Current consumption: 300 mA

• Adjacent channel rejection: = 65 dB

• Intermodulation attenuation: = 65 dB

• Receiving frequency: Max. 1680 receiving frequencies, adjustable in 25 kHz steps 20 frequency banks, each with up to 12 factory-preset channels, no intermodulation 1 frequency bank with up to 12 programmable channels

• RF sensitivity: < 2.5 µV for 52 dBA eff S/N

Squelch

• low: 5 dBµV

• middle: 15 dBµV

• high: 25 dBµV

Equalizer

• Preset 1: Flat

• Preset 2: Low Cut (-3 dB at 180 Hz)

• Preset 3: Low Cut/High Boost (-3 dB at 180 Hz, +6 dB at 10 kHz)

• Preset 4: High Boost (+6 dB at 10 kHz)

• Temperature Range: -10° C to +55° C

• Receiver Principle: True diversity

• Blocking: = 70 dB

SK 100 G4:

• Dimensions: Approx. 82 x 64 x 24mm

• Compander: Sennheiser HDX

• THD, total harmonic distortion: = 0.9 %

• Weight: (incl. batteries) approx. 160 g

• Signal-to-noise ratio: = 110 dBA

• RF output power: Max. 30 mW

• Switching bandwidth: up to 42 MHz

• Peak deviation: ±48 kHz

• Nominal deviation: ±24 kHz

• Operating time: Typically 8 h

• Modulation: Wideband FM

• Power supply: 2 AA batteries, 1.5 V or BA 2015 accupack (sold separately)

Current consumption

• at nominal voltage: typ. 180 mA

• with transmitter switched off: = 25 µA

• Input impedance: 40 kOhms, unbalanced / 1 MOhm

• Max. Input voltage: 3 Veff

• Powering: 3 V battery / 2.4 V rechargeable battery

• Transmission frequency: Max. 1680 transmitting frequencies, adjustable in 25 kHz steps 20 frequency banks, each with up to 12 factory-preset channels, no intermodulation 1 frequency bank with up to 12 programmable channels

AF frequency response

• Mic: 80 – 18,000 Hz

• Line: 25 – 18,000 Hz

• Temperature Range: -10° C to +55° C

• Frequency stability: = ±15 ppm

SALE: $679.99
FREE S&H in continental US (e-mail for international / offshore USA rates)
