WARM AUDIO WA-2A Professional Vintage Style Optical Compressor Leveling Amplifier Processor
WARM AUDIOWA-2A WARM AUDIO
Optical Compressor Leveling Amplifier
The Warm Audio WA-2A is a transformer-balanced, high-voltage, opto (light-controlled) all-tube compressor with a completely discrete signal path and through-hole component topology. It features custom, large-core Cinemag USA input and output transformers, four premium vacuum tubes, and Kenetek opto-cells.
Features:
-
USA-made CineMag input and output transformers
-
USA-made Kenetek T4B opto attenuator. Socketed to allow for retro-fitting with vintage (or other) opto-cells
-
Premium Tung-Sol and Electro-Harmonix tubes. 2 x 12AX7, 1 x 12BH7, 1 x 6AQ5 (or 6P1 - interchangeable)
-
Variable Pre-emphasis knob (via the back-panel) allows for compression hi-pass filtering
-
Stereo-link capability via TRS connector and knob on back panel
Specifications:
-
XLR and TRS balanced line level inputs - 600 Ω impedance
-
XLR and TRS balanced line level outputs - 600 Ω impedance
-
Frequency Response +/- 1 dB, 15 Hz to 20 kHz
-
Gain 40 dB +/- 1 dB
-
Input Level + 16 dB maximum
-
Output Level +10 dB nominal, + 16 dB maximum
-
Distortion Less than 0.5 % THD at +/- 10 dBm
-
Noise = - 74 dB
-
Attack Time: 10 milliseconds
-
Release Time: 0.06 seconds for 50% release; 0.5 to 5 seconds for complete release
-
Meter: shows both dB gain reduction and dB output
-
Power: 115/230 volts (switchable), 50/60 Hz
-
19" rack-mount chassis, 2U
-
Dimensions: 19" x 7" x 3.5"
-
Weight: 12 lbs
SALE: $949.99
FREE S&H in continental US (e-mail for international /offshore USA rates)
