YAMAHA MGP24X 24 Channel FX USB Audio Mixer with Digital Functions

YAMAHA
SKU:
181737
|
UPC:
4957812529464
$1,599.99
(No reviews yet)
Shipping:
Free Shipping
Current Stock:
Adding to cart… The item has been added

 MGP24X  YAMAHA

 24 Channel FX USB Audio Mixer

Not just for live bands and DJs, the MG Series mixing consoles can easily adapt to a truly impressive range of applications from portable PA to fixed installation. Now with the newly added digital functions and superior sound of the MGP24X, the possibilities are endless. 16 of Yamaha’s refined D-PRE mic preamps deliver a fat, rich, smooth tone that gives the MGP24X a significant advantage over any other mixer in its class. Yamaha's proprietary X-pressive EQ has captured ultimate analog authenticity by unlocking the mysterious secret behind the expressive sound-shaping capabilities of sought-after classic EQ modules. The MGP24X boasts 16 mix inputs with +48V phantom power and high-pass filter per channel, 24 line inputs (16 mono and 4 stereo), 6 AUX sends and 2 FX sends, 4 Group buses plus ST bus, 2 matrix outs, and 1 mono out. More than just a means of tweaking your mix, the precise response and very steep shelving of the high and low frequencies make the X-pressive EQ a powerful sound-shaping tool that essentially redefines the role that EQ plays in sound reinforcement. The MGP24X features Yamaha’s upgraded 1-knob compressors that feature LED indicators, allowing you to visually monitor when the compression “kicks in” on each channel.


Features:

  • 16 mic inputs with +48V phantom power and high-pass filter per channel

  • 24 line inputs (16 mono and 4 stereo)

  • 6 Aux sends and 2 FX sends

  • 4 Group buses + ST bus

  • 2 Matrix out, 1 mono out

Specifications:

  • Mixing capability

  • Mixing channels: 24 Line Inputs (16 mono and 4 stereo)

  • GROUP: 4 GROUP Buses + ST Bus

  • AUX: 6 AUX Sends + 2 FX Sends

  • MATRIX: 1 Matrix out

  • On-board processors: FX1:REV-X (8 PROGRAM, PARAMETER control) / FX2:SPX (16 PROGRAM, PARAMETER control)

  • Mic inputs: MIC: 16 (INPUTS HPF: 100Hz 12dB/oct)

  • Phantom power: 48V phantom power per channel

  • Line inputs: LINE: 16 mono + 4 stereo, CH INSERT: 16 RETURN: 1 stereo

  • Digital I/O: USB Device, iPod / iPhone

  • Total harmonic distortion: 0.02% (20Hz-20kHz@ +14dBu)

  • Frequency response: +0.5/-1.0dB 20Hz - 20kHz, refer to the nominal output level @1kHz

  • Hum & noise level Equivalent input noise: -128 dBu Equivalent Input Noise

  • Residual output noise: -94 dBu Residual Output Noise

  • Crosstalk: -74dB @ 1kHz

  • Power requirements: 100-240V 50Hz/60Hz

  • Power consumption: 86W max

  • Dimensions (WxHxD): 32.2" x 6.7" x 22.2"

  • Net weight: 34.2lb

SALE: $1599.99

FREE S&H in continental US (e-mail for international / offshore USA rates)
