YAMAHA RUIO16-D Dante/USB Audio Interface with Software

 RUIO16-D  YAMAHA

 16 Channel Dante/USB Interface with Software


Yamaha's RUIO16-D is a Dante-enabled audio interface that offers an ideal solution to engineers looking to integrate a highly stable plugin environment into their studio or live mixing system. The interface includes VST Rack Pro software and 30 standard plugins plus it's compatible with any VST plugins you own as well as VST3-compatible processors. A compact, rugged design makes the RUIO16-D ideal for life on the road or jumping from room to room in a studio and can easily be rack mounted. A pair of high-quality microphone preamps means the unit can be used for recording or acoustic measurement while providing a convenient bridge between Dante, analog, and USB signals. FOH engineers will appreciate the 16 Dante I/O channels the RUIO16-D provides, allowing them to use their favorite dynamic, EQ, and effects processors confidently in a live environment. There's even a USB bypass button on the front panel that skips the plugin processing if the case of a computer glitch, ensuring the system audio is not affected.

Yamaha RUIO16-D Features:

• An audio interface that serves as a bridge for Dante, USB, and analog signals

• A compact yet rugged interface

• High-quality preamps

• 16 channels of Dante I/O

• 18 channels of USB input

• 16 channels of USB output

• Offers a flexible, stable plug-in environment

• Bypass function for minimizing potential trouble

• Bundled with a wide variety of plug-ins

• Use as a multipurpose interface to handle plug-ins and acoustic measurement simultaneously

Yamaha RUIO16-D Specifications:

I/O

• Inputs: Analog Inputs (Mic / Line) x 2 (XLR)

• Outputs: Analog Outputs x 2 (XLR)

• Dante: Primary / Secondary (etherCON)

• Phones: 1 (TRS)

• USB: USB 2.0 (PC/Mac) x 1 (USB Type-C), DC Power input x 1 (USB Type-C)

• Dante: Number of I/O Channels 16 in / 16 out

• USB: Number of I/O Channels 18 in / 16 out (USB 2.0)

General specifications

• Sampling frequency rate External: 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz

• Signal delay: Less than 250 μs, Analog INPUT to Analog OUTPUT @Fs = 96 kHz Bypass: USB mode

• Power requirements: 5 V / 1.5 A

• Power consumption: 7.5 W

• Dimensions: 7.1"x 1.7"x 4.8" / 180mm x 42mm x 121mm

• Net weight: 2.2 lbs / 1.0 kg

SALE: $1299.99

FREE S&H in continental US (e-mail for international / offshore USA rates)
