YORKVILLE EF12P Active 4800w Total Peak PA System Speaker Pair

 EF12P  YORKVILLE

 4800w Total Peak Active PA Speaker Pair


In the 1980's, Yorkville Sound changed the face of high-powered portable speakers with the launch of the élite series. Indestructible wood cabinets with high output drivers offered PA professionals & weekend warriors alike a new level of high SPL speakers in portable packages. 30 years later, and we are changing the rules again.

Features:

• High Output, High Quality and extremely durable Dedicated Front of House box

• Completely Redesigned Next Generation Elite Cabinet

• ABS Coated Birch Plywood Cabinet Construction

• Multiband DSP Limiting with 4 Preset Playback Performance Modes

• 3-inch Titanium Diaphragm Compression Driver for Reduced Distortion at High SPL

• 12-inch Neodymium Woofer with 3-inch Voice coil

• iOS and Android App for Added Cabinet Control (Coming Soon)

• Made in Canada

Specifications:

• System Type: 2-Way
• Active or Passive: Active
• Program Power (Watts): 1200 Watts (2400 Watts Peak)
• Max SPL (dB): 131dB Peak (125dB Continuous)
• Frequency Response (Hz +/- 3dB): 47 - 16k (Hz +/- 3dB)
• Crossover Frequency (Hz): 1100
• Driver Configuration: 12-inch, 3-inch Diaphragm
• HF Driver(s): 3-inch Voice coil (Titanium Diaphragm)
• HF Dispersion (°H x °V): 60x40
• LF Driver(s): 12-inch Neo magnet w/3-inch Voice coil
• HF Power Amplifier (Watts): 300
• HF Amplifier Type: 3-Tier High Headroom
• LF Power Amplifier (Watts): 900
• LF Amplifier Type: Class-D
• Power Cable: 25 ft (7.6m) Heavy Gauge Detachable IEC
• In / Out Connections: 1 x XLR & 1/4-inch Combi-jack, RCA Line Inputs, 1 x XLR microphone Input, 1 x XLR & 1/4-inch Combi-jack Main Input, 1 x XLR-M Thruput
• Input Impedance (Bal/UnBal): 95KOhms / 90kOhms
• Input Sensitivity (Vrms Sine): +4dBv / 1.23V
• Controls: Mixer Enable, Mic Input w/level, Line Input w/level, DSP Mode (Club, Concert, Vocal, Custom), Sub (100Hz HP Filter), Bluetooth Control Enable, Master Level
• Bar Handles: 2 x Side / 1 x Top
• Flypoints: 8 x ¼-20 (2 Top, 2 Bottom, 2 Each Side, 2 Pullback)
• Pole Mount Adapter (1 3/8"-3.5cm): 1 Bottom (1 3/8-inch / 3.5cm)
• Enclosure Materials: ABS Coated Baltic Birch Plywood
• Dimensions (DWH xbackW, inches): 14.5 x 18.6 x 28.2 x 11.1
• Dimensions (DWH xbackW, cm): 36.8 x 47.25 x 71.6 x 28.2
• Weight (lbs/kg): 59 / 26.8

SALE: $3219.99

FREE S&H in continental US (e-mail for international / offshore USA rates)
