YORKVILLE SA115S Synergy Series Array 9000w Peak Active 15" PA Sub-Woofer

 SA115S  YORKVILLE

 9000w Total Peak Synergy Array Sub

The SA115S powered subwoofer is the companion piece to the SA102 full range speaker. Together, these components create a smaller, lighter and more portable Synergy Array system, without sacrificing the impressive bass Synergy is known for. The Tom Danley patented 15" tapped-horn design allows for the SA115S to deliver an astonishing 9000 watts (peak), and 4500 watts (program) in a compact cabinet.

Keeping versatility and ease of use as Synergy's key features, the SA115S has multiple stand adapters on the top and side surfaces, allowing the SA102 top boxes to be arrayed in multiple performance scenarios.

The ideal solution for delivering big sound in smaller environments and growing with every sized venue. The SA115S with the SA102 is easy to lift, carry, and configure without sacrificing sonic integrity.

Features:

• Tapped Horn Powered Subwoofer

• 4500 watts (program), 9000 watts (peak)

• 1x 15-inch LF woofers with 4.5" Voice Coil

• Exceptionally high output and deep bass

• Measured MAX SPL 129dB Cont. 135 dB Peak

• Frequency Response (Hz +/- 3db): 31Hz-100Hz

• Crossover Frequency (Hz): 100 Hz low-pass

• Dimensions (DWH x backW, inches): 36.625 (including Casters) x 17.750 x 35.250

• Made in Canada

Specifications:

• System Type: Active Subwoofer

• Active or Passive: Active

• Power Rating (Watts): 4500 Watts Program (9000 Watts Peak)

• Measured Max SPL (C-Weighted, Max Hold): 129dB Cont. 135 dB Peak

• Frequency Response (Hz +/- 3dB): 31Hz-100Hz

• Crossover Frequency (Hz): 100 Hz lowpass

• Cabinet Configuration: Tapped Horn

• Driver Configuration: 1x15" LF woofer

• LF Driver(s): 15" Neodymium with 4.5" Voice Coil

• LF Power Rating(Watts): 4500 Watts Program (9000 Watts Peak)

• LF Impedance (Ohms): 4 ohm Load

• LF Protection: Excursion, Voice Coil Thermal (RMS)

• LF Amplifier Type: Class D

• Cooling Scheme: Convection

• Power Cable: Removable Locking Powercon True Input and Loop Thru Output

• Power Switch: Yes

• Inputs: 1 XLR with 2x XLR Parallel out, Impedance 35k ohms

• Input Sensitivity (Vrms Sine): Line in 1.4 at center, 0.56 at max

• Level Controls: Volume, -∞,0dB,8dB (Min, Top, Max)

• EQ Controls: Thermal Limiter Advance for power consumption management

• Limiter: Excursion, Thermal (RMS), Clipping

• LED Indicators: Power, Excursion Limit, Thermal (RMS) Limit, Input Clip, Activity

• Enclosure Materials: Multiply 15mm Birch Plywood

• Stacking Feature: Interlocking Rubber Feet (Sides)

• Covering / Finish: Paint

• Dimensions (DWH xbackW, inches): 36.625 (including Casters) x 17.750 x 35.250

• Dimensions (DWH xbackW, cm): 93 x 45 x 82

• Weight (lbs/kg): 165/74.9

SALE: $3759.99

FREE S&H in continental US (e-mail for international / offshore USA rates)
