ZOOM PODTRAK-P4 4 Channel Portable Recorder USB Audio Interface
ZOOMPODTRAK-P4 ZOOM
4 Channel Portable Recorder USB Interface
24-bit/44.1kHz Portable Recorder and USB Audio Interface with 4 XLR Inputs, 4 Sound Pads, Headphone Outputs, and Switchable Phantom Power.
Professional-Quality Audio Made Easy
Meet the PodTrak P4, a compact, feature-rich, and affordable tool that elevates your podcasting experience. With this device, you can effortlessly capture professional-quality audio, no matter where you record.
Versatile Mic Inputs with Zoom Preamps
The P4 is equipped with Zoom's top-notch preamps, providing up to 70dB of gain to accommodate even the most demanding microphones. You can trust the P4 to deliver exceptional sound quality for your podcast recordings.
Seamless Headphone Monitoring for Everyone
With four independent headphone outputs, each having its own volume control, the P4 ensures that every participant can hear everything clearly. No more struggling to follow the conversation; the P4 takes care of it all.
Effortless Remote Interviews
Incorporating remote interviews into your podcast has never been easier. Simply connect your phone to the P4 using a TRRS cable or link your computer via USB to your preferred conferencing software. The P4's built-in mix-minus feature automatically eliminates echo and feedback for seamless remote communication. For even more convenience, you can use the optional Zoom BTA-2 Bluetooth Receiver (sold separately) to wirelessly connect your phone and record remote guests.
Customizable Sound Pads for Enhanced Creativity
With the P4's customizable Sound Pads, you can instantly trigger music, ads, jingles, and pre-recorded interviews, adding a professional touch to your podcast. Choose from 11 pre-recorded presets or easily load your own sounds for personalized content.
Long Recording Sessions Made Possible
The P4 operates on just 2 AA batteries, providing up to 3 hours of recording time. If you need extended battery life, you can also use a USB battery to keep your podcasting sessions going.
Versatility as an Audio Interface
The PodTrak P4 is not just a standalone recorder; it can serve as a 2-input, 2-output audio interface as well. This means you can directly record your podcasts to your computer, Android, or iOS* device, expanding your recording options further.
Live-Stream Your Podcasts
Take your podcasting to the next level by live-streaming your content. With the P4's capabilities, you can easily connect and engage with your audience in real-time, making your podcasts more interactive and dynamic.
Features:
-
Gain control knobs and mute buttons for each input
-
Phantom power for all XLR inputs
-
Prevents feedback from call audio using Mix-Minus function
-
Easily connect your phone using the TRRS connection
-
Trigger sound effects using 4 assignable Sound Pads
-
All input sources can be recorded on separate tracks
-
Records directly to SD, SDHC and SDXC cards up to 512GB
-
Two-input, Two-output USB audio interface
-
Class-compliant mode for iOS compatibility
-
Up to 4 hours of use with 2 AA batteries or USB power supply
Specifications:
Channels
-
Number of input channels: 4 (mono/stereo)
-
Number of output channels: 1 (headphone Å~ 4)
Connectors
-
Mic: XLR jacks (2: HOT)
-
Smart phone connection jack: TRRS mini jack (4 contacts, TIP: L, RING 1: R,RING 2: GND, SLEEVE: MIC)
-
USB: USB Type-C (audio interface and mass storage functions)
-
Note: Use a USB cable that supports data transfer. USB bus power is supported.
-
DC 5 V: USB Type-C (for power supply)
-
Headphones: 3.5mm stereo mini
Recorder
-
Formats: WAV 44.1 kHz, 16-bit, mono/stereo
-
Recording media: 4 GB−32 GB SDHC-compliant cards (Class 10 or higher); 64 GB−512 GB SDXC-compliant cards (Class 10 or higher)
-
Audio interface: 44.1 kHz, 16-bit, 2-in/2-out
Power
-
Phantom power: +48 V
-
Power: 2 AA batteries (alkaline, NiMH or lithium)
-
AC adapter (ZOOM AD-17): DC 5 V/1 A (USB bus power is supported)
-
Est. continuous operation time using batteries: Recording 44.1 kHz/16-bit/4-ch audio to SD card (when 48 V is OFF and headphone impedance is 63 Ohms)
-
Alkaline batteries: Approximately 4 hours
-
NiMH batteries (1900 mAh): Approximately 4.5 hours (recommended)
-
Lithium batteries: Approximately 9 hours
Dimensions and Weight
-
External dimensions (W x D x H): 112 x 155 x 47 mm
-
Weight (unit only): 290 g
SALE: $169.99
FREE S&H in continental US (e-mail for international / offshore USA rates)
