WARM AUDIO WA-2MPX Authentic Reproduction Dual-Channel Tube Mic Preamp

 WA-2MPX  WARM AUDIO

 Authentic Reproduction Dual-Channel Tube Mic Preamp

The WA-2MPX is an authentic reproduction of the most revered microphone tube preamp that pioneered the birth of rock ‘n’ roll & radio-ready hits. During the golden-era of tape recording, this style of vintage tube preamp became the signature sound in the signal chain of hit recordings including Elvis Presley, Les Paul, and Bing Crosby - and is a sound that is still pursued by today’s biggest artists. With premium components, true-to-original circuit design, and tape saturation control, the WA-2MPX authentically reproduces all the analog tone of the original to bring vintage warmth & color to your sound.

Features:

Authentic Reproduction Of The Most Revered Tape-Era Tube Mic Preamp
The WA-2MPX is based on the 351-style tube preamplifier found in American tape machines that pioneered the birth of rock ‘n’ roll & radio-ready hits.

Power & Versatility For A Wider Range Of Analog Tone
Delivering an impressive 300v of raw power & 90dB of tube gain, WA-2MPX achieves clean gain & powerful volume, that pushes the tubes to saturate just like the most timeless analog gear.

Premium Components & Handwired Construction For An Authentic Vintage Experience
Hand-assembled with three premium tubes per channel paired with custom-wound true-to-spec USA CineMag transformers, the WA-2MPX authentically reproduces all the analog tone of the original.

Selectable, All-Analog Tape Saturation
WA-2MPX uses discrete analog components that provide compression, saturation, and non-linear frequency response for authentic tape-era reel-to-reel sound at 15IPS.

Hi-Pass (80Hz) & Low-Pass (2kHz) Filters to Refine Tone
The 2kHz low-pass filter allows you to further shape and focus your tone, dialing in ultimate midrange warmth & punch. The 80Hz hi-pass filter helps remove unwanted bass noise from unruly sources.

Hand-Inspected & Tested at Warm Audio HQ in Austin, Texas
Carefully inspected at Warm Audio Headquarters in Austin, Texas by trained engineers & musicians with a passion for helping you sound your best.

Specifications:

• Authentic Reproduction Of The Most Revered Tape-Era Tube Preamp

• Fully Discrete, Hand-Built Construction With 3 Tubes Per Channel For Ultimate Analog Tone

• Selectable Tape Saturation Adds Harmonic Distortion & Natural Compression

• 90dB Of Analog Tube Gain Per Channel

• Custom-Wound, Large-Core CineMag USA Transformers

• Mic Input: 600Ω Transformer (6000Ω Rated)

• Mic Input With “Tone” Engaged: 150Ω Transformer (1500Ω Rated)

• Premium (2X) 12AX7 & (1X) 12AU7 Vacuum Tubes

• 600Ω Output Attenuator

• Engage High Gain Control For An Added 20db (From 70db To 90db) Of Clean Gain For Low-Output Mics And Low-Volume Sources

• 48v Phantom Power & Polarity Switch

• Classic Warm Audio Tone Control That Alters The Input Transformer Impedance Adding Extra Analog Color

• 80Hz High-Pass Filter To Control Unruly Bass Frequencies

• 2kHz Low-Pass Filter To Focus Preamp Power & Warmth On Mids For Added Punch

• Inputs: XLR Mic, TS Instrument & TRS Line.

• Outputs: XLR / TRS Line Level

• VU Meter Level Indication

SALE: $1399.99
FREE S&H in continental US (e-mail for international / offshore USA rates)
